In the long history of the automotive industry, the evolution of truck lighting is not only a microcosm of technological iteration but also a testament to the continuous improvement of safety and efficiency in commercial transportation. From the kerosene lamps transplanted from horse-drawn carriages in the late 19th century to today's adaptive LED systems integrated with artificial intelligence, every innovation in truck lighting has profoundly reflected the unique needs of commercial transportation scenarios. This article will systematically review the century-long development of truck lighting from primitive illumination to intelligent safety systems, analyzing how technological breakthroughs, regulatory standards, and application scenarios have collectively shaped the modern truck lighting system.

The Age of Open Flame: The Transition from Kerosene Lamps to Acetylene Lamps (1880s-1920s)

The starting point of truck lighting is in line with early automobiles but has taken a unique technological path due to the particularity of commercial use. In 1887, when kerosene lamps were first fixed to the front of early motor vehicles, it marked the beginning of vehicle lighting history. This lighting method, inherited from the horse-drawn carriage era, used a glass lampshade to protect against wind and relied on a wick to draw up kerosene for combustion and light emission. However, it had insufficient brightness and required frequent refueling, performing particularly poorly on bumpy freight roads.

The acetylene lamp, which appeared in the 1880s, represented the first technological leap in truck lighting. Compared with kerosene lamps, acetylene lamps generated light by burning gas produced from the chemical reaction between calcium carbide and water. They not only increased brightness by 3-4 times but also better resisted adverse weather conditions such as wind and rain. Interestingly, the jolting of the truck during travel intensified the chemical reaction, which in turn improved the lighting effect. This "the more jolting, the brighter" characteristic unexpectedly matched the poor road conditions of the early days. Until around 1921, despite the need for continuous calcium carbide refueling and the explosion risk of acetylene lamps, they remained the mainstream choice for long-distance freight vehicles due to the immaturity of electric light technology.

During this period, truck lighting had not yet formed a unified standard. The lamps mostly had round cast iron casings, and their installation positions were arbitrary, with some even directly fixed on the sides of the cargo compartment. The lighting function was also extremely singular, only providing limited-range illumination for the front, lacking safety designs such as turn signals and rear warnings, and the accident rate of night transportation remained high.

The Early Electrification Era: The Popularization of Incandescent Lamps and Sealed Beam (1920s-1960s)

With the maturation of automotive electrical systems, truck lighting finally entered the electrification era. The invention of the spiral tungsten filament incandescent lamp in 1913 laid the foundation for electric light sources in vehicles. This design, which filled nitrogen to protect the filament, not only increased brightness by 50% but also greatly improved the shock resistance, making it suitable for the severe vibrations during truck travel. However, due to the lag of truck electrical systems, it was not until 1925 that, with the maturity and mass production of battery technology, incandescent lamps gradually replaced acetylene lamps to become the mainstream.

The sealed beam headlamp, which appeared in the 1920s, was an important innovation in truck lighting. This design, which integrated the filament, reflector, and lens into one unit, greatly improved the stability and lifespan of the lighting, making it particularly suitable for long-distance freight vehicles. General Motors first introduced interior lights into truck cabs in 1920. Although it was not the main light source for illumination, it marked the beginning of truck lighting focusing on the driver's operating environment.

During this period, technological progress was accompanied by the initial establishment of regulations. In the 1940s, the United States began to standardize the installation height and beam angle of truck headlights, and the EU also introduced early vehicle lighting standards, requiring trucks to be equipped with at least two sets of headlights and rear brake lights. China, in the 1950s, began to standardize the configuration of incandescent lamp lighting systems on domestic trucks (such as the Jiefang CA10) with the introduction of Soviet technology, using 24V voltage to meet the electrical needs of diesel engines.

Technological Breakthrough: The Revolution of Halogen Lamps and Composite Headlights (1960s-1990s)

The advent of halogen lamps in the 1960s triggered the second technological revolution in truck lighting. In 1964, the halogen tungsten lamp produced by the French "Saub" company, by filling the bulb with halogens such as iodine or bromine, enabled the filament to work at a higher temperature, increased light efficiency by about 50%, and doubled the lifespan. Compared with passenger cars, due to cost sensitivity and maintenance convenience requirements, the popularization of halogen lamps in trucks was about 10 years later, and it became the mainstream configuration in the 1970s.

The emergence of composite headlights marked the entry of truck lighting into the modular era. This design, which separates the bulb, reflector, and lens, allows for the replacement of individual components when the lamp is damaged, greatly reducing maintenance costs. For the freight industry, which is sensitive to operating costs, this characteristic is highly attractive. At the same time, the functions of truck lights began to diversify, with fog lights, turn signals, and high-mounted brake lights gradually becoming standard, and by the late 1970s, trucks had generally been equipped with complete lighting signal systems.

Regulatory standards played a key role in promoting progress during this period. The ECE R48 regulation of the United Nations Economic Commission for Europe detailed the installation position, light intensity distribution, and testing methods of truck lighting devices. The US Federal Motor Vehicle Safety Standard FMVSS 108 set strict requirements for light color, visibility, and durability. The introduction of these standards prompted truck manufacturers to shift from simply pursuing brightness to focusing on lighting safety and standardization.

The High-Performance Era: The Rise of Xenon Lamps and Intelligent Control (1990s-2010s)

The application of high-intensity discharge lamps (HID) in the 1990s brought truck lighting into the high-performance stage. This technology, commonly known as xenon lamps, generates blue-white light similar to daylight through high-voltage arc discharge, with brightness three times that of halogen lamps and a lifespan extended by ten times. It is particularly suitable for scenarios requiring long-distance lighting, such as mining areas and long-haul routes. However, due to the high cost and the need for a stable electrical system, xenon lamps were initially only used in high-end trucks, such as the Volvo FH series and Mercedes-Benz Actros models.

The installation of the Sylvania Xenarc HID system on the Ford F250 in 2000 became a typical case of xenon lamp application in trucks. Its lighting range reached 1.5 times that of traditional halogen lamps, while power consumption was reduced by 35%, significantly improving the night driving safety of heavy-duty pickups. However, xenon lamps also exposed some shortcomings in truck applications: the light penetration was insufficient in rainy and snowy weather, and the high beams flickered noticeably on bumpy roads, limiting their popularity in harsh working conditions.

During this period, intelligent control technology began to be introduced into truck lighting. In the late 2000s, some high-end trucks were equipped with automatic dimming systems that could automatically switch between high and low beams based on the distance of oncoming vehicles. In 2013, Volvo first adopted a split V-shaped headlight design in its FH series, integrating turn signals into the upper edge of the headlights and adding turning auxiliary lights on the door panels, greatly improving lateral visibility during turns. China revised the GB 4785 standard in 2004, requiring newly produced trucks to be equipped with headlights that meet the light intensity distribution standards, promoting the upgrading of domestic truck lighting technology.

Solid-State Lighting: The Widespread Adoption of LED Technology (2010s to Present)

In the second decade of the 21st century, the maturation of LED technology brought revolutionary changes to truck lighting. Compared with traditional light sources, LEDs have the advantages of low energy consumption (only 1/10 that of halogen lamps), long lifespan (up to 100,000 hours), and strong shock resistance, perfectly meeting the operational needs of commercial trucks. In 2012, Penske Truck Leasing retrofitted Truck-Lite LED headlights on 5,000 tractors, marking a milestone in the large-scale application of LED lighting in commercial trucks. These LED lamps, initially developed for military use and tested on the battlefields of Iraq and Afghanistan, can withstand extreme environmental challenges.

The development of LED technology has driven the multifunctional integration of truck lights. The LED headlights of the Peterbilt 589 model, with a modular design, not only save 30% energy but also integrate lens heaters and hard-coated protective lenses, which can work stably in environments ranging from -40℃ to 80℃, significantly enhancing resistance to ultraviolet light and fine sand abrasion. The Ouman Galaxy 9 integrates headlights, turn signals, fog lights, and daytime running lights into one unit, achieving a light-shadow reflection effect through a "starry light belt" design, which not only expands the lighting range but also reduces the drag coefficient to 0.348.

Intelligence has become the core feature of the LED era. Modern truck LED systems can now achieve intelligent functions such as adaptive high beams, cornering assistance, and adverse weather modes. The adaptive headlights of the Volvo FH can automatically adjust the beam according to the position of oncoming vehicles to avoid glare; through camera and sensor data analysis, they can automatically switch lighting modes in rainy, snowy, and foggy weather. The Chinese commercial vehicle LED market has grown rapidly since 2019, breaking through 5 billion yuan in 2023, and is expected to reach a hundred billion scale by 2030, with intelligence and personalization becoming the main development directions.

Special Scenarios and Future Trends: From Engineering Assistance to Vehicle-Road Coordination

The lighting needs of engineering trucks and special vehicles have driven the development of specialized lighting technologies. In 2024, Atlas Copco upgraded its HiLight series of lighting vehicles, using SMD LED technology to achieve a uniform illuminance of 20 lux, covering a lighting area of 7,000 square meters. With IP69 water resistance and IK10 impact resistance, these vehicles can be used in extreme environments such as mines and disaster relief. These mobile lighting devices have become a standard for night-time engineering work, with a brightness equivalent to 50 traditional halogen lamps.

Current truck lighting is developing in three directions: First, deeper intelligence, with adaptive systems based on driver gaze tracking and head direction, can adjust the lighting direction in real time according to the driver's focus of attention; second, functional integration, combining LED light strips with the vehicle-to-everything (V2X) system, can display navigation information and vehicle status warnings; third, green energy saving, by optimizing optical design and intelligent control, further reduces energy consumption and supports the extended range of new energy trucks.

Laser headlights, as the next-generation technology, have been tested in passenger cars, but their application in trucks still faces challenges. Although laser lighting has a range of up to 600 meters, its high cost and insufficient penetration in rainy and foggy weather make it unlikely to be widely adopted in trucks in the short term. More realistically, vehicle-road coordination technology may reshape the logic of truck lighting—by integrating road infrastructure lighting with vehicle active lighting, a "vehicle-road-lamp" integrated safety system can be achieved.

Conclusion: The Eternal Pursuit of Safety and Efficiency

The century-long history of truck lighting is essentially the history of the eternal pursuit of safety and efficiency in commercial transportation. From kerosene lamps to intelligent LED systems, every technological breakthrough has originated from solving pain points in real-world scenarios: Acetylene lamps adapted to the poor road conditions in the early days, halogen lamps balanced cost and performance, and LED lamps met the needs for energy saving, environmental protection, and long life. The evolution of regulatory standards has pushed technological upgrades from the outside, with the ECE, FMVSS, and GB standards systems jointly building a global safety framework for truck lighting.

In the future, with the development of autonomous driving technology, truck lights may go beyond traditional lighting functions to become an important interface for vehicle-environment interaction. But no matter how technology evolves, the core mission of truck lights remains unchanged—to light the way in the dark, safeguarding millions of freight drivers and supporting the round-the-clock operation of the global logistics network. In a sense, the light of truck lamps not only illuminates the road but also reflects the continuous progress of human commercial civilization.
